In modern transformer core silicon steel processing, production efficiency and precision have become critical factors determining product quality and operational cost. Traditional multi-stage processing methods often lead to inefficiency, inconsistent accuracy, and increased manual handling.
The 300 One-cut Three-punch Cut-to-Length Line is designed as an integrated solution that streamlines the entire silicon steel processing workflow into a single continuous production system.
It is specifically engineered to handle silicon steel coil leveling, feeding, multi-position punching, and cut-to-length shearing, ensuring stable and efficient output for transformer core manufacturing.
Key System Functions:
Integrates multiple processing stages into one continuous production line
Enables synchronized leveling, feeding, punching, and shearing operations
Reduces manual handling and inter-process material transfer
Improves dimensional consistency of silicon steel laminations
Supports long-hour continuous transformer core lamination production
The system is built around a Finger CNC control platform combined with a full-servo drive architecture, which ensures precise motion coordination and stable operational performance. This allows operators to maintain high production accuracy even under high-speed continuous transformer core silicon steel processing conditions.
To meet the strict requirements of transformer core manufacturing, this production line is engineered with a focus on stability, precision, and automation efficiency. Each functional module is designed to work seamlessly within a unified system architecture.
The machine combines leveling, feeding, multi-position punching, and cut-to-length shearing into a single continuous production line. This integration minimizes material transfer between machines, reducing handling errors and improving overall production consistency.
Equipped with a full-servo drive system, the equipment ensures precise coordination of feeding and processing actions. This results in stable dimensional accuracy and improved repeatability during high-speed production cycles.
The Finger CNC interface provides a user-friendly control experience, allowing operators to set processing parameters such as feeding length, punching sequence, and cutting size with ease. This reduces operational complexity and improves production efficiency.
The machine frame is constructed with heavy-duty steel to maintain stability during continuous high-speed operation. Its vibration-resistant design helps maintain consistent machining accuracy over long production periods.
Designed for transformer core lamination production environments, the system supports uninterrupted operation, making it suitable for large-volume manufacturing of transformer core laminations.
The technical configuration of the 300 One-cut Three-punch Cut-to-Length Line is built around transformer core silicon steel processing reliability and precision control requirements. Each component is selected to ensure long-term operational stability and processing accuracy.
Parameter | Specification |
Product Name | 300 One-cut Three-punch Cut-to-Length Line |
Applicable Material | Thin silicon steel sheets/coils |
Control System | Finger CNC (supports open-source & customized closed-loop control) |
Drive System | Full-servo drive system |
Core Components | Delta inverters, HIWIN/AIRTAC linear guides, Taiwan-made ball screws, Schneider/Siemens low-voltage parts |
Core Functions | Leveling, Feeding, Multi-position punching, Shearing, Automatic error correction, Finished product collection |
Air Pressure Requirement | 0.5–0.7 MPa |
Processing Precision | High-precision feeding with strict control over dimensional tolerance and burr height |
Application Fields | Transformer core manufacturing, transformer core lamination processing, silicon steel sheet cutting, step-lap transformer core production |
Certification | ISO9001 Quality Management System |
Delivery Time | Approximately 90 working days after deposit |
Warranty | 12-month whole machine warranty + lifelong technical support |
Payment Terms | T/T or L/C, 30% deposit, 70% balance before shipment |
The 300 One-cut Three-punch Cut-to-Length Line is designed for precision processing of silicon steel coils in transformer core lamination production. It plays a key role in producing transformer core silicon steel laminations where dimensional accuracy, burr control, and consistent punching quality are required for stable final assembly performance.
The equipment is mainly used in continuous production scenarios involving transformer core manufacturing, where integrated cutting and punching operations are needed.
Used for producing silicon steel laminations for transformer cores. The equipment ensures stable feeding, precise punching, and accurate cut-to-length processing, which helps maintain consistent stacking performance during core assembly and supports stable magnetic efficiency in final transformer applications.
Applied in cutting and punching silicon steel sheets used for transformer cores. The machine helps maintain accurate sheet dimensions, clean edges, and stable lamination quality for transformer core assembly.
Suitable for transformer core lamination production where consistent punching alignment, cutting accuracy, and burr control are required. The integrated processing system helps improve production continuity and lamination consistency.
Used for preparing silicon steel laminations for step-lap transformer core manufacturing. The equipment supports accurate feeding, multi-position punching, and stable cut-to-length shearing during continuous production.
To ensure stable performance and long-term operational safety, the equipment follows a structured operation workflow from setup to production.
Before starting the machine, operators should ensure that:
Electrical power supply is stable and correctly connected
Compressed air pressure is maintained within 0.5–0.7 MPa
Silicon steel coil is properly loaded and aligned on the feeding system
All safety inspection procedures have been completed
Proper preparation helps ensure smooth startup and reduces the risk of operational interruptions.
Through the Finger CNC control interface, operators can configure production settings based on transformer core lamination requirements, including:
Feeding length adjustment
Punching sequence and positioning
Cutting length settings
Batch production quantity
Before entering full production mode, a short trial run is recommended to verify:
Feeding accuracy and stability
Punching alignment precision
Cutting smoothness and edge quality
This step ensures all system components are operating under correct conditions.
After successful testing, the system enters continuous production mode:
Servo-controlled feeding ensures stable material movement
Punching and cutting processes operate in synchronized cycles
Finished products are automatically discharged for collection
This enables high-efficiency, low-labor production.
After completing production:
Safely power off the system
Clean residual material from feeding and cutting areas
Inspect punching tools and cutting components for wear
Perform lubrication and routine maintenance checks
Regular maintenance ensures long-term equipment stability and extends service life.
Q1: How does the Finger CNC system improve the daily operation of the machine?
A: The Finger CNC system provides an intuitive, user-friendly interface that significantly lowers the learning curve for operators. It allows for the rapid input of complex parameters such as feeding lengths and multi-position punching coordinates. Furthermore, its open-source architecture supports customized closed-loop control, ensuring the machine can be tailored to your specific processing requirements while maintaining high-speed stability.
Q2: What measures are in place to ensure the longevity of the punching and shearing mechanisms?
A: The durability of our cutting and punching units is rooted in our material selection and structural design. We utilize high-grade, wear-resistant alloys for the tooling, driven by a robust hydraulic and full-servo system that ensures smooth, shock-free engagement. Regular maintenance, such as monitoring hydraulic oil levels and die wear, combined with our precision HIWIN linear guides, ensures these critical components maintain their sharp, burr-free performance over an extended lifespan.
Q3: Can this machine handle the specific requirements of both large power transformers and small home appliance motors?
A: Yes. The 300 One-cut Three-punch Cut-to-Length Line is designed for transformer core silicon steel sheet processing. Its precise tension control and adjustable feeding mechanisms allow it to process thin silicon steel sheets with the tolerances required for different transformer core lamination designs, supporting stable punching, shearing, and stacking quality.
Q4: What is the standard protocol for machine installation and initial testing at our facility?
A: Before the machine is shipped, it undergoes exhaustive no-load and load testing in our factory using real materials. Upon arrival at your facility, the primary setup involves connecting the power supply, ensuring the air pressure meets the 0.5–0.7 MPa requirement, and threading the coil. We provide comprehensive operation guides and remote technical support to assist your auxiliary personnel in executing a seamless startup and formal production cycle.
Q5: How do the payment terms and warranty policy protect our investment?
A: We offer flexible and secure payment options, accepting both T/T and L/C, structured as a 30% deposit with the 70% balance due before shipment. Your investment is further protected by our comprehensive 12-month whole-machine warranty, which includes free replacement parts for any non-human induced damage, backed by our commitment to lifelong technical support.
